Bugle head self-drilling drywall screw fine thread for metal construction

51
.
03
GBS PH-(TSD)

The Bugle Head Self-Drilling Drywall Screw with fine thread for metal construction is a specialized fastening element designed for mounting drywall on metal frameworks, such as steel or aluminum profiles. This innovative solution combines a screw and a drill, allowing for convenient and effective fastening of drywall without the need for pre-drilling holes. It is suitable for installing drywall on metal profiles with a maximum drilling capacity of 2.2 mm.

Applications:

Bugle head self-drilling drywall screws for metal construction are used in the following applications:

  • Partition Wall Installation: Utilized for mounting drywall sheets on metal frameworks to create internal partition walls in buildings.
  • Ceiling Installation: Employed for securing drywall sheets to metal frames of suspended ceilings.
  • Metal Frameworks: Ideal for fastening drywall on metal structures, such as steel or aluminum profiles.
  • Commercial and Industrial Projects: Commonly used in construction projects where metal frameworks are key structural components.

Benefits:

  • Durability: These screws are made from durable materials, ensuring long lifespan and corrosion resistance.
  • Quick Installation: With the built-in drill, drywall can be quickly and conveniently mounted on metal profiles without pre-drilling holes.
  • Stable Connection: The self-drilling thread and precisely engineered screws provide stable and secure connections.
  • Versatile Use: Suitable for various types of metal frameworks and construction projects, making them a versatile tool for builders.
DOWNLOADABLE DOCUMENTS
Declarations of conformity

Recommended

Group
5103

Product variants

Step 1. Select initial parameters and confirm selection By selecting parameters you narrow down the list of products in the table in step 2

Attribute
Variants available
Diameter d [mm]
Length L [mm]
Packaging type
Head diameter D [mm]
Recess
Variety of coating
Unit of measure
Availability

Step 2. Browse product variants and use additional filters

Browse product variants and use additional filters
Material index
More attributes
Diameter d [mm] Length L [mm] Packaging type Head diameter D [mm] Recess Variety of coating Unit of measure Availability Show More
5103035025PHF1QO
3.5 25 Blister 8.6 PH 2 phosphated coating BOX
5103035025PHFDXK
3.5 25 Cardboard 8.6 PH 2 phosphated coating KG
5103035025PHFDXT
3.5 25 Cardboard 8.6 PH 2 phosphated coating THS
5103035025PHFK
3.5 25 Cardboard 8.6 PH 2 phosphated coating KG
5103035025PHFT
3.5 25 Bag 8.6 PH 2 phosphated coating THS
5103035035PHBDXK
3.5 35 Cardboard 8.6 PH 2 phosphated coating KG
5103035035PHFDXK
3.5 35 Cardboard 8.6 PH 2 phosphated coating KG
5103035035PHFDXT
3.5 35 Cardboard PH phosphated coating THS
5103035035PHFK
3.5 35 Cardboard 8.6 PH 2 phosphated coating KG
5103035035PHFT
3.5 35 Bag 8.6 PH 2 phosphated coating THS
5103035045PHFDXK
3.5 45 Cardboard 8.6 PH 2 phosphated coating KG
5103035045PHFDXT
3.5 45 Cardboard PH phosphated coating THS
5103035045PHFK
3.5 45 Cardboard 8.6 PH 2 phosphated coating KG
5103035045PHFT
3.5 45 Cardboard 8.6 PH 2 phosphated coating THS
5103035055PHFDXK
3.5 55 Cardboard 8.6 PH 2 phosphated coating KG
5103039011PHFDXK
3.5 11 Cardboard 8.6 PH 2 phosphated coating KG
5103039025PHFDXT
3.5 25 Cardboard 8.6 PH 2 phosphated coating THS
5103039035PHFDXT
3.5 35 Cardboard 8.6 PH 2 phosphated coating THS
5103039045PHFDXT
3.5 45 Cardboard 8.6 PH 2 phosphated coating THS
