Dee shackle

63
.
22

The Dee shackle is a structural element characterized by its simple design, specifically engineered for effectively connecting various structural components. Its functionality is based on simplicity and durability, making it an indispensable tool in various industrial fields.

Applications:

  • Construction: The dee shackle is used in steel, wooden, and concrete structures to connect beams, columns, and other structural elements.
  • Marine Industry: Employed as fastening elements in ship, dock, or offshore platform constructions.
  • Energy Sector: Utilized in power station structures for securing and connecting different components.
  • Automotive Industry: The dee shackle can be used to secure various components in vehicle manufacturing.

Benefits:

  • Simplicity: The straightforward design makes the shackles easy to use and install.
  • Durability: The materials used ensure longevity and resistance to weather conditions.
  • Versatility: The availability of various sizes and shapes makes dee shackles adaptable to different constructions.
  • Connection Stability: The dee shackle enables the creation of strong and lasting structural connections.
View in store
DOWNLOADABLE DOCUMENTS
Declarations of conformity

Recommended

Group
6322

Product variants

Step 1. Select initial parameters and confirm selection By selecting parameters you narrow down the list of products in the table in step 2

Attribute
Variants available
Type
Dimension d [mm]
Dimension D [mm]
Dimension L [mm]
Dimension A [mm]
Dimension B [mm]
Acceptable load [kg]
Rated load [kg]
Dimension C [mm]
Dimension H [mm]
Unit of measure
Availability

Step 2. Browse product variants and use additional filters

Browse product variants and use additional filters
Material index
More attributes
Type Dimension d [mm] Dimension D [mm] Dimension L [mm] Dimension A [mm] Dimension B [mm] Acceptable load [kg] Rated load [kg] Dimension C [mm] Dimension H [mm] Unit of measure Availability Show More
6322050S
5mm 5.0 10 80 80 20 PCS
6322060LS
6mm 6.0 12 100 24 PCS
6322060S
6mm 6.0 12 100 100 24 PCS
6322060T0016S
6mm 6,0 160 PCS
6322080S
8mm 8.0 16 200 200 32 PCS
6322080T0016S
6mm 6.0 6 8 6 12 160 34 18 PCS
6322100S
10mm 10.0 20 320 320 40 PCS
6322120S
12mm 12.0 25 520 520 48 PCS
6322120T0063S
12mm 12.0 12 16 12 24 630 66 36 PCS
6322140S
14mm 14.0 28 650 650 56 PCS
6322160S
16mm 16.0 32 800 800 63 PCS
6322160T0100S
16mm 16.0 16 21 16 32 1000 89 48 PCS
6322180S
18mm 18.0 36 950 1000 71 PCS
6322200S
20mm 20.0 38 1100 1100 76 PCS
6322200T0160S
20mm 20.0 20 26 19 40 1600 110 61 PCS
6322220S
22mm 22.0 44 1500 1500 82 PCS
6322220T0200S
22mm 22.0 22 29 21 43 2000 121 67 PCS
6322240T0250S
24mm 24.0 24 33 23 48 2500 130 73 PCS
6322250S
25mm 25.0 47 2000 97 PCS
6322270T0300S
27mm 27.0 27 38 24 54 3000 148 83 PCS
6322280S
28mm 28.0 56 3000 3000 106 PCS
6322300T0400S
30mm 30.0 30 41 30 60 4000 165 91 PCS
6322320S
32mm 32.0 57 3500 131 PCS
6322360T0500S
36mm 36.0 36 47 34 71 5000 195 109 PCS
6322380S
38mm 38.0 76 4000 139 PCS
6322390T0630S
39mm 39.0 39 52 37 78 6300 210 119 PCS
6322450T0800S
45mm 45.0 45 60 42 90 8000 245 139 PCS
6322480T1000S
48mm 48.0 48 66 47 95 10000 260 147 PCS
6322060MRPS
PCS
6322080MRPS
PCS
6322120MRPS
PCS
