Fine thread thin hex nut INOX

I15
.
28

The fine thread thin hex nut inox is a precision fastening element designed for effective and durable connections across a variety of applications. Made from high-quality stainless steel inox, this nut combines strength, corrosion resistance, and versatility, making it ideal for use in areas where a solid fastening is required in limited spaces.

Applications:
The fine thread thin hex nut inox is widely used in various fields such as electronics, automotive, and anywhere a secure fastening is needed in confined spaces.

Benefits:

  • Durability: Constructed from stainless steel inox, this nut ensures long-lasting performance and corrosion resistance, extending its lifespan.
  • Compact Design: The low profile of the nut allows installation in areas with limited space while maintaining connection stability.
  • Precision Threading: The fine thread provides precise and secure fastening, which is crucial in applications requiring accuracy.
  • Versatility: This nut performs exceptionally well across different industries and applications, making it a versatile fastening element.
  • Resistance to External Exposure: Its resistance to weather conditions makes the nut suitable for outdoor applications.

Recommended

Group
I1528

Product variants

Step 1. Select initial parameters and confirm selection By selecting parameters you narrow down the list of products in the table in step 2

Attribute
Variants available
Dimension d [mm]
Dimension m [mm]
Dimension s [mm]
Thread pitch
Material
Standard
Unit of measure
Availability

Step 2. Browse product variants and use additional filters

Browse product variants and use additional filters
Material index
More attributes
Dimension d [mm] Dimension m [mm] Dimension s [mm] Thread pitch Material Standard Unit of measure Availability Show More
I1528080100A2D439T
M8 4.0 13 1.00 A2 THS
I1528100100A2D439T
M10 5 17 1.00 A2 DIN 439 THS
I1528100100A4D439T
M10 5 17 1.00 A4 THS
I1528100125A2D439T
M10 5 17 1.25 A2 THS
I1528100125A4D439T
M10 5 17 1.25 A4 THS
I1528120125A2D439T
M12 7 19 1.25 A2 THS
I1528120125A4D439T
M12 6.0 19.0 1.25 A4 THS
I1528120150A2D439T
M12 7 19 1.50 A2 THS
I1528120150A4D439T
M12 6.0 19.0 1.50 A4 THS
I1528140150A2D439T
M14 7.0 22.0 1.50 A2 THS
I1528160100A2D439T
M16 8 24 1.00 A2 THS
I1528160150A2D439T
M16 8 24 1.50 A2 THS
I1528160150A4D439T
M16 8.0 24.0 1.50 A4 THS
I1528180100A2D439T
M18 9 27 1.00 A2 THS
I1528180150A2D439T
M18 9 27 1.50 A2 THS
I1528180150A4D439T
M18 9 27 1.50 A4 THS
I1528200150A2D439T
M20 9 30 1.50 A2 THS
I1528200150A4D439T
M20 10.0 30.0 1.50 A4 THS
I1528220150A4D439T
M22 10 32 1.50 A4 THS
I1528240150A2D439T
M24 12.0 36.0 1.50 A2 THS
I1528240150A4D439T
M24 12.0 36.0 1.50 A4 THS
I1528240200A4D439T
M24 12.0 36.0 2.00 A4 THS
I1528300150A2D439T
M30 12 46 1.50 A2 THS
I1528300150A4D439T
M30 12 46 1.50 A4 THS
I1528300200A2D439T
M30 12 46 2.00 A2 THS
I1528300200A4D439T
M30 12 46 2.00 A4 THS
I1528330200A4D439T
M30 14 50 2.00 A4 THS
I1528360150A2D439T
M36 14 55 1.50 A2 THS
I1528360300A4D439T
M36 14 55 3.0 A4 THS
