Fischer DHM metal insulation plug

57
.
46

Metal insulation plug for fastening fire-resistant insulation boards
Advantages
The metal insulation plug provides fire resistance R 120 and can therefore be used in conditions requiring fire resistance
The DTM 80 insulation plate for soft insulating materials (ordered separately) facilitates storage and reduces costs.
Fast hammer-in installation reduces work effort.
The geometry of the pin allows installation in aerated concrete without pre-drilling, which shortens the installation time.
The DHM insulation plug is available in hot-dip galvanised or A2 stainless steel.
The fischer DHM insulation plug is a metal fastener for pressure-resistant insulation boards. The fire resistance class R 120 ensures secure fastening of fire-resistant boards. The DHM fastener is designed for pre-installation. Fast hammer-in installation reduces work effort and speeds up work. Mineral or glass wool boards, glass foam elements and lightweight wood wool boards can be installed.

Send product inquiry

Product inquiry form

Recommended

Group
5746

Product variants

Step 1. Select initial parameters and confirm selection By selecting parameters you narrow down the list of products in the table in step 2

Attribute
Variants available
Dimension tfix [mm]
Availability

Step 2. Browse product variants and use additional filters

Browse product variants and use additional filters
Material index
More attributes
Dimension tfix [mm] Availability Show More
5746040FISS
40
5746070FISS
70
5746100FISS
100
5746130FISS
130
5746160FISS
160
5746210FISS
210
5746260FISS
260
