Turnbuckle nut

63
.
71
NN235
View in store

Recommended

Group
6371

Product variants

Step 1. Select initial parameters and confirm selection By selecting parameters you narrow down the list of products in the table in step 2

Attribute
Variants available
Dimension d [mm]
Dimension L [mm]
Tensile load capacity [kN]
Dimension d1 [mm]
Unit of measure
Availability

Step 2. Browse product variants and use additional filters

Material index
More attributes
Dimension d [mm] Dimension L [mm] Tensile load capacity [kN] Dimension d1 [mm] Unit of measure Availability Show More
6371080110BATS
M8 112 19.0 7.7 PCS
6371100125BATS
M10 123 35.0 7.8 PCS
6371120125BATS
M12 125 51.0 9.6 PCS
6371160170BATS
M16 168 93.0 9.9 PCS
6371200200BATS
M20 200 140.0 12.0 PCS
6371220220BATS
M22 216 166.0 12.0 PCS
6371240255BATS
M24 255 186.0 12.0 PCS
6371270255BATS
M27 255 260.0 14.5 PCS
6371300255BATS
M30 255 300.0 16.0 PCS
6371360290BATS
M36 310 380.0 16.5 PCS
